Topran Turbolader pakking
Uitlaatgasturbo, Metaal, Afvoerzijde
| Laadtype | Uitlaatgasturbo |
| Materiaal | Metaal |
| Inbouwplaats | Afvoerzijde |
Uitlaatgasturbo, Plaatstaal, Bovenaan, voor terugloop
| Laadtype | Uitlaatgasturbo |
| Materiaal | Plaatstaal |
| Inbouwplaats | Bovenaan |
| Naloop/terugloop | Voor terugloop |
Uitlaatgasturbo, Plaatstaal, Afvoerzijde, Staalpakking
| Laadtype | Uitlaatgasturbo |
| Materiaal | Plaatstaal |
| Dikte [mm] | 1,5 |
| Inbouwplaats | Afvoerzijde |
| Bouwwijze afdichting | Staalpakking |
Uitlaatgasturbo, Plaatstaal, Bovenaan, voor terugloop
| Laadtype | Uitlaatgasturbo |
| Materiaal | Plaatstaal |
| Inbouwplaats | Bovenaan |
| Naloop/terugloop | Voor terugloop |
| Bouwwijze afdichting | Staalpakking |
Uitlaatgasturbo, FPM (Fluor-Kautschuk), O-ring, Aanvoerzijde
| Laadtype | Uitlaatgasturbo |
| Materiaal | FPM (Fluor-Kautschuk) |
| Dikte [mm] | 3,5 |
| Binnendiameter [mm] | 44,45 |
| Vorm | O-ring |
| Inbouwplaats | Aanvoerzijde |
Uitlaatgasturbo, Na turbolader, Uitlaatbocht, Staalpakking
| Laadtype | Uitlaatgasturbo |
| Binnendiameter [mm] | 45 |
| Inbouwplaats | Na turbolader, Uitlaatbocht |
| Bouwwijze afdichting | Staalpakking |
Aluminium
| Materiaal | Aluminium |
| Dikte [mm] | 1,5 |
| Voor aanbevolen reparatie aanwijzingen, zie toebehoorlijst | |
| Binnendiameter [mm] | 12 |
| Buitendiameter [mm] | 17 |
FCR (fluorcarbonrubber), O-ring
| Binnendiameter [mm] | 9 |
| Buitendiameter [mm] | 12 |
| Dikte [mm] | 1,5 |
| Materiaal | FCR (fluorcarbonrubber) |
| Vorm | O-ring |
Flensbevestiging, FCR (fluorcarbonrubber), Met plastic laag (coat), Uitlaatgasturbo
| Bevestigingswijze | Flensbevestiging |
| Materiaal afdichtlip | FCR (fluorcarbonrubber) |
| Contactoppervlakte | Met plastic laag (coat) |
| Laadtype | Uitlaatgasturbo |
| Materiaal | Plaatstaal |
| Naloop/terugloop | Voor terugloop |
| Bouwwijze afdichting | Staalpakking |
Oliepan, Uitlaatgasturbo, op versnellingsbakbehuizing, FPM (Fluor-Kautschuk)
| Inbouwplaats | Oliepan, Uitlaatgasturbo, op versnellingsbakbehuizing |
| Materiaal pakking | FPM (Fluor-Kautschuk) |
| Binnendiameter [mm] | 14 |
| Buitendiameter [mm] | 18 |
| Dikte [mm] | 2 |
| Vorm | O-vorm |
Uitlaatgasturbo, FCR (fluorcarbonrubber), O-ring, Onder
| Laadtype | Uitlaatgasturbo |
| Materiaal | FCR (fluorcarbonrubber) |
| Dikte [mm] | 2,7 |
| Binnendiameter [mm] | 7,59 |
| Vorm | O-ring |
| Inbouwplaats | Onder, Bovenaan |
| Naloop/terugloop | Voor aanvoer |
Uitlaatgasturbo, FCR (fluorcarbonrubber), O-ring, Onder
| Laadtype | Uitlaatgasturbo |
| Materiaal | FCR (fluorcarbonrubber) |
| Dikte [mm] | 2,7 |
| Binnendiameter [mm] | 17,12 |
| Vorm | O-ring |
| Inbouwplaats | Onder |
| Naloop/terugloop | Voor terugloop |
Uitlaatgasturbo, Bovenaan, Staalpakking
| Laadtype | Uitlaatgasturbo |
| Inbouwplaats | Bovenaan |
| Bouwwijze afdichting | Staalpakking |
Uitlaatgasturbo, Uitlaatbocht, Staalpakking
| Laadtype | Uitlaatgasturbo |
| Inbouwplaats | Uitlaatbocht |
| Bouwwijze afdichting | Staalpakking |
